24V D Frame Push Pull Solenoid AS1031 | Automatic Toys & Locker Components

The AS1031 Push And Pull Solenoid 24V D Frame Type is a compact, high-performance component tailored for automatic toys, medical mailboxes, and lockers. Engineered with a sturdy D frame structure, it delivers consistent push-pull force for precise, repeated operations, ensuring reliable functionality in small-scale automation scenarios. Its 24V power supply balances efficiency and safety, making it suitable for low-voltage toy and medical device applications. Compact in size, it integrates seamlessly into limited-space designs of mailboxes and lockers, with a durable build that withstands frequent use. We offer flexible OEM customization to match specific device requirements, along with competitive bulk pricing and fast delivery, making it the optimal choice for manufacturers of toys, medical storage, and locker systems.

Product Video

Product Specification

Brand	AstSolenoid	Model Number	AS 1031
Rated Voltage (V)	DC 24V	Rated Power(W)	4.5 W
Work Mode	Push Pull Type	Holding Force (N)	1500 GF
Stroke(mm)	Customized	Reset Time(s)	1 S
Service Life	300 Thousand Times	Certification	CE,ROHS,ISO9001,
Material	Carbon Steel Housing with Ni. Coating	Lead Wire Length(mm)	200
Install Style	Mounnted Screw Holes	Tolerance of Dimension	+/- 0.1 MM
Water-proof	None	Insulation Class	F 155 Degree
Hi-Pot Test	AC 600V 50/60Hz 1 s	DC Resistance	134 Ω
Working Temperature	-10°C-100°C	Duty Cycle	1-100%
Materials	RoHS Compliance	Payment Term	TT, or LC At Sight
Sample Order	Yes	Warranty	1 Year
MOQ	MOQ 500–1000 pcs	Supply Ability	5000 pcs per Week
Delivery Time	30 Days	Port of Loading	shenzhen

Voltage source	DC Power DC24V
Stroke Distance	4-10mm (Adjustable )
Force	1.5-8N (Adjustable according to your requirement)
Power wattage	. 24 W
Power Current	1.0 A
Resistance	10Ω
Lifespan	≥200,000 times
Working Cycle	0.3 s On, 5 s Off

Product Description

Metal Housing: Carbon Steel housing, It is electroplated with Zinc or Nickle coating. It is undergone 96 hours salt spray testing and it is anticorrosion with high temperature standard and compliance with RoHS.
Metal Plunger: Carbon Steel material, It is electroplated with Zinc coating with smooth surface. It is passed 96 hours salt spray testing and it is anticorrosion and compliance with RoHS Standard.

Heat dissipation

The feature of the frame type solenoid is easier to dissipate compared with the round type, tubular type and the suction cup electromagnet. Most of its bobbin copper coils are exposed to the outside, which can discharge the heat in time to make sure smoothness in work, without jamming, stopping or burning situation.. Therefore, the frame type solenoid is popular in good quality and has good heat dissipation capacity.

Advantages

AS 1031 Solenoid is a miniature push-pull electromagnet mass-produced by Dr. Solenoid at 2020. The frame type electromagnet of AS 1031 can be made into a push electromagnet and a pull solenoid as per your specification. The product has small size, easy installation, low cost and is widely used in the market for automation equipment, automatic toys, medical mailboxes and lockers, etc.
