Product Specification
| Brand | AstSolenoid | Model Number | AS 0616 |
| Rated Voltage (V) | DC 12 V or 24V | Rated Power(W) | 28.8 W |
| Work Model | Rotary Movement | Holding Force (N) | 150 GF |
| Stroke(mm) | Customized | Reset Time(s) | 1 S |
| Service Life | 500 Thousand Times | Certification | CE,ROHS,ISO9001, |
| Material | Carbon Steel Housing | Lead Wire Length(mm) | 200 |
| Install Style | screw | Tolerance of Dimension | +/- 0.1 MM |
| Water-proof | None | Insulation Class | B |
| Hi-Pot Test | AC 600V 50/60Hz 2s | Non-excitation Holding Force | 0 |
| Working Temperature | -10°C-100°C | Duty Cycle | 1-100% |
| Thread Depth(mm) | / | Payment Term | TT, or LC At Sight |
| Sample Order | Yes | Warranty | 1 Year |
| MOQ | 1000 PCS | Supply Ability | 5000 pcs per Week |
| Delivery Time | 30 Days | Port of Loading | shenzhen |
Product Detailed Description
Frequently Asked Questions (FAQ) – AS 0616 Rotary Solenoid
1. What applications does the AS 0616 rotary solenoid serve?
The AS 0616 rotary solenoid finds primary application in money accounting machines, currency counters, note sorting systems, and banking automation equipment. It facilitates precise angular motion, which is essential for functions like locking, releasing, positioning, and diverting banknotes.
2. How does a rotary solenoid function within a money counting machine?
A rotary solenoid operates by converting electrical energy into rotational movement. Upon energization, the magnetic field induces the rotor to rotate to a predetermined angle, thereby enabling the rapid and precise mechanical actions necessary in high-speed cash handling systems.
3. What rotation angles are offered for the AS 0616?
Standard rotation angles encompass 15°, 30°, 45°, 60°, and 90°. Furthermore, custom rotation angles can be engineered to meet the specific requirements of individual money accounting machines.
4. Can the AS 0616 rotary solenoid handle continuous use?
Indeed. The AS 0616 is built for both intermittent and high-frequency applications. If you need it for continuous duty, we can provide custom coil designs and thermal optimizations to keep things running smoothly.
5. What voltage choices are available?
We offer standard voltage options of DC 6V, 12V, and 24V. For OEM and specialized financial equipment, we can also provide custom voltage ratings.
6. How dependable is the AS 0616 rotary solenoid?
This solenoid is built to last, with a robust magnetic circuit, bearings that resist wear, and an optimized coil design. It’s engineered to deliver consistent performance, even in the demanding world of banking.
7. Is the AS 0616 customizable?
Absolutely. You can adjust the rotation angle, torque output, voltage, mounting structure, shaft type, connector, and lead wire length to fit the specific needs of your money accounting machine design.
8. Where is this rotary solenoid typically used?
It’s a common component in banking equipment, financial automation systems, vending machines, ticketing systems, ATMs, and commercial cash handling devices.
9. Does the AS 0616 adhere to international standards?
Yes, the AS 0616 rotary solenoid can be made to meet RoHS standards, and its production follows ISO 9001 quality management systems.
10. How do I choose the right rotary solenoid for my machine?
Consider the required torque, rotation angle, duty cycle, voltage, response time, and available installation space. Our engineering team is available to help you select or customize the ideal AS 0616 solution.
